Custom Plastic Vacuum Forming Services
Our Vacuum Forming Services
Vacuum forming is a termoform süreci where a heated plastic sheet is stretched over a mold and shaped using vacuum pressure. It is a highly efficient and cost-effective solution for producing large and complex plastic components.
Paylaş：
Nasıl Çalışır
Plastik levha ısıtılır
Levha kalıbın üzerine yerleştirilir
Vakum havayı uzaklaştırır
Malzeme kalıp üzerinde sıkıca şekillenir
Parça soğur ve kesilir
Malzemeler
- Polikarbonat (PC)
- PMMA /Akrilik
- ABS
- PET/PETG
- PVC
- Talep üzerine diğer mühendislik plastikleri
Kalınlık ve Boyut Aralığı
Uygulamalar
- Makine kapakları
- Ekran muhafazaları
- Tepsiler ve ambalajlar
- Koruyucu paneller
- Endüstriyel bileşenler
Temel Avantajlar
- Enjeksiyon kalıplamaya göre daha düşük kalıp maliyeti
- Büyük parçalar için uygundur
- Hafif ve dayanıklı
- Esnek tasarım kabiliyeti
- Kısa üretim döngüleri
Kalite ve Hassasiyet
Yüksek hacimli çalışmalarda tutarlı kalınlık, pürüzsüz yüzey ve boyutsal kararlılık sağlıyoruz.
Neden Bizi Seçmelisiniz
- 13+ yıllık plastik işleme deneyimi
- Gelişmiş bükme ve işleme ekipmanları
- Yetenekli teknisyenler
- Özel OEM ve ODM desteği
SSS
Q: What materials are suitable for vacuum forming?
A: Common materials include PC, acrylic, PET, PVC, ABS and PS thermoplastic sheets.
Q: What is the maximum forming size?
A: Standard size up to 1240*2440mm, extra-large curved & irregular products are available.
Q: Will polycarbonate (PC) sheet turn white or become thin after forming?
A: Proper temperature control and pre-blowing process effectively avoid whitening and uneven wall thickness.
Q: Can vacuum formed parts be CNC milled and laser trimmed?
A: Yes, secondary processing like trimming, hole drilling, grooving and polishing is supported.
Q: What is the applicable sheet thickness range?
A:Stable forming for sheets from 1mm to 12mm.
Q: Can you make molds and produce per drawings or samples?
A: Yes, custom molds based on drawings or samples, accept small and mass orders.
Q: Are vacuum formed parts weather-resistant for outdoor use?
A:PC parts feature good temperature resistance and UV resistance for outdoor use; ordinary sheets are for indoor use only.
Q: How about production cycle and delivery time?
A: Fast sample making, sufficient mass production capacity and stable lead time.
Q: What is the difference between vacuum forming and ısı bükme?
A: Vacuum forming fits deep-curve 3D shells; simple radian prefers heat bending for lower cost.
Q: Do you provide OEM and ODM one-stop vacuum forming service?
A: Full-service including design, mold opening, forming, finishing and assembly is available.
